Feature
- Capacities from 300kg to 2000kg
- Lifting speeds up to 30m/minute
- IP65-66 protection for outdoor/wet environments
- Aluminum die-cast housing
- Electromagnetic and mechanical brakes
- Touchscreen and remote control options
- Overload protection and limit switches
- Compliant to BGV-D8 and CE standards
Product Description
KRC stage electric chain hoists deliver powerful and precision lifting for demanding entertainment rigging applications. With a range of control and configuration options, they can serve both permanent venue installations and touring productions.
The hoists feature robust die-cast aluminum housings with high IP65-66 ratings, allowing usage outdoors or in wet conditions often faced in productions. Redundant electromechanical braking systems ensure safety and control.
Available models include:
| Model | Load Chain Diameter (mm) | Power (KW) | Lifting Speed (m/min) | Lifting Height (m) | Voltage (V) | Capacity (kg) |
|---|---|---|---|---|---|---|
| SU-0.5 | 5 | 1.5 | 4 | ≥10 | 220-440 | 500 |
| SU-1.0 | 7.1 | 1.5 | 4 | ≥10 | 220-440 | 1000 |
| SU-2.0-2 | 9 | 2.2 | 4 | ≥10 | 220-440 | 2000 |
| SU-2.0-1 | 7.1 | 1.5 | 2 | ≥10 | 220-440 | 2000 |
| Model | Load Chain Diameter (mm) | Power (KW) | Lifting Speed (m/min) | Chain Falls | Lifting Height (m) | Voltage (V) | Capacity (kg) |
|---|---|---|---|---|---|---|---|
| SU-G+0.5-1 | 5 | 1.5 | 4 | 1 | ≥10 | 220-440 | 500 |
| SU-G+0.5-2 | 5 | 1.9 | 16 | 1 | ≥10 | 220-440 | 500 |
| SU-G+2.0-1 | 7.1 | 1.5/1.9 | 4/8 | 1 | ≥10 | 220-440 | 1000 |
| SU-G+1.0 | 7.1 | 1.9 | 4 | 1 | ≥10 | 220-440 | 1000 |
| SU-G+2.0-2 | 7.1 | 1.9 | 2 | 2 | ≥10 | 220-440 | 2000 |
KRC stage hoists provide advanced functionality like position encoders for integration with digital controllers, touchscreen control stations, and remote control pendants. This allows anything from basic operation to synchronized group control motions.
Built to comply with EN and BGV standards, they offer reliable, heavy-duty lifting for theaters, concerts, TV studios and more.
Please contact us for more detailed parameters
